Basic Info.
Model NO.
50728
Processing Technology
Electrolytic Foil
Base Material
Aluminum
Insulation Materials
Epoxy Resin
Brand
Jhwl
Surface Finish
HASL, Enig, OSP
Solder Mask
Green/Black/White/Red/Blue/Yellow
Biggest Panel Size
610mm*508mm
Hole Posito
+/-0.075mm(3mil) CNC Driling
Transport Package
OEM
Specification
35*25*27
Trademark
JHWL
Origin
China
Product Description
LED display
| Item | Specification | |
| 1 | Number of Layer | 1-26Layers(standard) |
| 2 | Material | FR3,Aluminum ,FPC |
| 3 | Surface Finish | HASL(LF),Gold plating,Enig ,lmmersion gold,lmmersion Tin,OSP |
| 4 | Finish Board Thickness | 0.2mm-6.00mm(8mil-126mil) |
| 5 | Coppeer Thickness | 1/2oz min;12oz max |
| 6 | Solder Mask | Green/Black/White/Red/Blue/Yellow |
| 7 | Min.Trace Width&Line Spacing | 0.075mm/0.1mm(3mil/4mil) |
| 8 | Min Hole Size | 0.15mm |
| 9 | Driling Hole Size | 0.15~6.5mm |
| 10 | Min Soldermask Bridge | 0.1mm |
| 11 | Orifice diameter | 10:1 |
| 12 | Board Thickness | 0.20mm-10mm |
Q. What is your best pricQ.What kind of documents/files do you need for quotation?
For PCBA project, please send us your Gerber files, BOM(bill of material),and pcb specification.
For plastic enclosure/junction box/shell, please send us your 3D drawing,and material.
For ODM/Engineer Development service, please consult our sales engineer for more details.
Q. How to keep our product information and design file secret ?
We are willing to sign a NDA effect by customers side local law and promising tokeep customers data in high confidential level.
For plastic enclosure/junction box/shell, please send us your 3D drawing,and material.
For ODM/Engineer Development service, please consult our sales engineer for more details.
Q. How to keep our product information and design file secret ?
We are willing to sign a NDA effect by customers side local law and promising tokeep customers data in high confidential level.
Q.How long does it take for PCB and PCBA Quote ?
*Please note that the following detail will speed up evaluation:
Material:
Board thickness:
Copper thickness:Surface finish:
Solder mask color:
Silkscreen color:
Q.How can we guarantee you receive an good quality product?
For PCB, we will use Flying Probe Test, E-test etc. for it.
For PCBA, we need you to offer us a method or test fixture for the function test.Before that, our inspectors will use microscope and X-ray to check the IC footwelding or bad solder etc.
For PCB, we will use Flying Probe Test, E-test etc. for it.
For PCBA, we need you to offer us a method or test fixture for the function test.Before that, our inspectors will use microscope and X-ray to check the IC footwelding or bad solder etc.
